UNIVERSAL ROBOTS

UNIVERSAL ROBOTS
Product Detail

KEY FEATURES:

Easy programming

 Patented technology lets operators with noprogramming experience quickly set up and operate our cobots with intuitive, 3Dvisualization. Simply move the robot arm to desired waypoints or touch thearrow keys on the easy-to-use touchscreen tablet.

Fast set up

UniversalRobots has revolutionized robot set-up, reducing typical robotic deploymentmeasured in weeks to a matter of hours. The average set-up time reported by ourcustomers is only half a day. The out-of-box experience for an untrainedoperator to unpack the robot, mount it, and program the first simple task istypically less than an hour.

Flexibledeployment of Cobots

Dont be limited bydedicated robotics. Universal Robots are lightweight, space-saving, and easy tore-deploy to multiple applications without changing your production layout.Moving the cobot to new processes is fast and easy, giving you the agility toautomate almost any manual task, including those with small batches or fastchange-overs. The cobot is able to re-use programs for recurrent tasks.

Collaborative and safe robots

Nowyou can replace human operators in dirty, dangerous, and dull jobs to reducerepetitive strain and accidental injuries. Eighty percent of the thousands ofUR robots worldwide operate with no safety guarding (after risk assessment),right beside human operators. The safety system of our robots is approved andcertified by TÜV (The German Technical Inspection Association).

Technicalspecifications

Model

UR3

UR5

UR10

Payload

3 kg / 6.6 lbs

5 kg / 11 lbs

10 kg / 22 lbs

Reach

500 mm / 19.7 in

850mm / 33.5 in

1300 mm / 51.2 in

Degrees of freedom

6 rotating joints

6 rotating joints

6 rotating joints

Noise

<65dB

72dB

72dB

Robot mounting

Any

Any

Any

Footprint

Ø 128mm

Ø 149mm

Ø 190mm

Weight with cable

11 kg / 24.3 lbs

18.4 kg / 40.6 lbs

28,9 kg / 63.7 lbs
